AP31F44017K5M
Power Supply
Features:
- 17,500W Power
- IP65 Enclosure
- Bidirectional AC-DC
- 93% Typical Efficiency
Product Description
This high-voltage bidirectional AC-DC power converter gives users 440Vac to 380Vdc voltage conversion with 17,500W (17.5kW) power. The AP31F44017K5M is designed for rugged environments where harsh conditions require IP65 enclosure, 10°C to +50°C operating temperature, and shock/vibe protection. This unit provides 93% typical efficiency with a forced fan cooled thermal design.
This is a new release — more details coming soon!
