Our Products
1–24 of 46 results
-
1PH400
The 1PH400 is a 400Hz VME power supply with a SWaP optimized design. With its... More details >>1PH400
Telecom, Single Phase AC, AC SINGLE PHASE, Single, Enclosed, Conduction, Military, Mil-Std, 6U, Aircraft, 400Hz, Embedded Technology, VME, Industrial,
Single Slot VME Power Card
Features:
- AC‐DC Power Supply Card
- Single Phase 400Hz 115/220Vac Input
- 115/220Vac per MIL‐STD‐704F*
- Single Output, 600/650W
- MIL‐STD‐810F Environmental *
- MIL‐STD‐461E EMI *
, 1PH400-001, 1PH400-002, 1PH400-003, +28Vdc 23.2A 650W, +48Vdc 12.5A 600W, +12Vdc 50A 600W, 1, 2, 3, 4, 600W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
1PH402
This 6U AC-DC power supply offer rugged design in compact space. This unit has dual... More details >>1PH402
Telecom, Single Phase AC, AC SINGLE PHASE, Enclosed, Conduction, Military, Multiple, Mil-Std, 6U, Aircraft, 400Hz, Embedded Technology, VME, Industrial,
Single Slot VME Power Card
Features:
- AC‐DC Power Supply Card
- Single Phase 400Hz 115/220Vac Input
- Dual Output, 500W Max Combined Output
- 115/220Vac per MIL‐STD‐704F*
- MIL‐STD‐810F Environmental *
- MIL‐STD‐461E EMI *
, 1PH402-001, +5Vdc 40A 200W, +12Vdc 25A 300W, 500W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
1PH404
This 115/220Vac power supply has the option for 3 or 4 outputs in varying voltages... More details >>1PH404
Telecom, Single Phase AC, AC SINGLE PHASE, Conduction, Military, Multiple, Mil-Std, 6U, Aircraft, 400Hz, Embedded Technology, VME, Industrial,
Power Supply Card
Features:
- 115/220Vac per MIL-STD-704F*
- 3 or 4 Output, 375W combined
- MIL-STD-810F Environmental *
- MIL-STD-461E EMI *
- Single Slot VME Power Card
, 1PH404-001, 1PH404-002, +5Vdc 40A 200W, +3.3Vdc 45A 150W, +3.3Vdc 15.1A 50W, +12Vdc 5A 60W, +12Vdc 10.4A 125W, 12Vdc 1A 12W, 375W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
1PH404A
This dual slot AC-DC power supply is designed for use in VME systems. This single... More details >>1PH404A
Telecom, Single Phase AC, AC SINGLE PHASE, Military, Multiple, Mil-Std, 6U, Forced Air, Aircraft, 400Hz, Embedded Technology, VME, Industrial,
Single Slot VME Power Card
Features:
- AC‐DC Power Supply Card
- Single Phase 400Hz 115/220Vac Input
- 3 or 4 Outputs, 375W Max Combined Output
- 115/220Vac per MIL‐STD‐704F*
- MIL‐STD‐810F Environmental *
- MIL‐STD‐461E EMI *
, 1PH404A-001, 1PH404A-002, +5Vdc 40A 200W, +3.3Vdc 45A 150W, Available Outputs: 15.1A 50W, +12Vdc 5A 60W, +12Vdc 10.4A 125W, -12Vdc 1A 12W, 375W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
1PH60
This single slot AC-DC power supply is available in several variations for output (see chart... More details >>1PH60
Telecom, Single Phase AC, AC SINGLE PHASE, Single, Conduction, Military, 60Hz, Mil-Std, 6U, Aircraft, Embedded Technology, VME, Industrial,
Single Slot VME Power Card
Features:
- AC‐DC Power Supply Card
- Single Phase 60Hz 115/220Vac Input
- 115/220Vac per MIL‐STD‐704F and MIL‐STD‐1399A/B *
- Single Output, 600/650W
- MIL‐STD‐810F Environmental *
- MIL‐STD‐461E EMI *
, 1PH60-001, 1PH60-002, 1PH60-003, 1PH60-004, 1PH60-005, +28Vdc 23.2A 650W, +48Vdc 12.5A 600W, +12Vdc 50A 600W, +5Vdc 80A 400W, +24Vdc 25A 600W, 600W, 650W, 400W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
1PH604
This filtered AC-DC power supply can be configured for three or four outputs (+5Vdc, +3.3Vdc,... More details >>1PH604
Telecom, Single Phase AC, AC SINGLE PHASE, Conduction, Military, 60Hz, Multiple, Mil-Std, 6U, Aircraft, Embedded Technology, VME, Industrial,
Single Slot VME Power Card
Features:
- AC‐DC Power Supply Card
- Single Phase 60Hz 115/220Vac Input
- 3 or 4 Outputs, 375W Max Combined Output
- 115/220Vac per MIL‐STD‐704F *
and MIL‐STD‐1399A/B * - MIL‐STD‐810F Environmental *
- MIL‐STD‐461E EMI *
, 1PH604-001, +5Vdc 40A 200W, +3.3Vdc 45A 150W, +12Vdc 5A 60W, -12Vdc 1A 12W, 375W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
1PH604A
The 1PH604A is a pluggable slide-in AC power supply designed for use in VME systems.... More details >>1PH604A
Telecom, Single Phase AC, AC SINGLE PHASE, Military, 60Hz, Multiple, Mil-Std, 6U, Forced Air, Aircraft, Embedded Technology, VME, Industrial,
Dual Slot VME Power Card
Features:
- AC‐DC Power Supply Card
- Single Phase 60Hz 115/220Vac Input
- 3 or 4 Outputs, 375W Max Combined Output
- 115/220Vac per MIL‐STD‐704F*
and MIL‐STD‐1399A/B * - MIL‐STD‐810F Environmental *
- MIL‐STD‐461E EMI *
, 1PH604A-001, 1PH604A-002, +5Vdc 40A 200W, +3.3Vdc 45A 150W, +12Vdc 10.4A 125W, +12Vdc 5A 60W, +3.3Vdc 15.1A 50W, -12Vdc 1A 12W, 375W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
1PH60A
This filtered AC power supply is a compact 6U VME power card suitable for a... More details >>1PH60A
Telecom, Single Phase AC, AC SINGLE PHASE, Single, Military, 60Hz, Mil-Std, 6U, Forced Air, Aircraft, Embedded Technology, VME, Industrial,
Single Slot VME Power Card
Features:
- AC‐DC Power Supply Card
- Single Phase 60Hz 115/220Vac Input
- One Output, 600/650W Max
- 115/220Vac per MIL‐STD‐704F and MIL‐STD‐1399A/B *
- MIL‐STD‐810F Environmental *
- MIL‐STD‐461E EMI *
, 1PH60A-001, 1PH60A-002, 1PH60A-003, 1PH60A-004, 1PH60A-005, +28Vdc 23.2A 650W, +48Vdc 12.5A 600W, +12Vdc 50A 600W, +5Vdc 80A 400W, +24Vdc 25A 600W, 600W, 650W, 400W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
BG2802
The BG2802 is an enclosed DC-DC power converter with a single 28Vdc output. This military... More details >>BG2802
Zero Hertz (DC), Single, Conduction, Military, Mil-Std, Aircraft, DC-DC, Rugged, DC LOW VOLTAGE, Industrial,
Enclosed Case Power Converter
Features:
- DC-DC Power Converter
- Single Output, 238W Max
- 28Vdc per MIL-STD-704A/E/F *
- MIL-STD-1275A/B/D*
- MIL-STD-810F Environmental *
- MIL-STD-461E EMI *
, BG2802-01, BG2802-02, BG2802, +14.5Vdc 15A 218W, +5Vdc 15A 75W, +19Vdc 12.5A 238W, 218W, 290W Surge, 238W, 290W Surge, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
BW2901
This single phase, single output power supply takes 115VAC 377W input and converts it into... More details >>BW2901
1-Phase AC-DC, AC SINGLE PHASE, Single, Conduction, Military, 60Hz, Mil-Std, Aircraft, Industrial,
Single Output with Three Output Options
Features:
- AC-DC Power Supply
- Single Phase 47-62 Hz 115 Vac Input
- 300W, 325W, or 600W Power Supply
- With Current Sharing Capability
- MIL-STD-1399 Section 300 A/B.*
, BW2901-001, BW2901-002, BW2901-003, +24Vdc 25A 600W, +28Vdc 10.7A 300W, +24Vdc 12.5A 300W, 600W, 300W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
CS7061A
This multiple output AC-DC power supply is enclosed in a conduction cooled metallic case and... More details >>CS7061A
1-Phase AC-DC, AC SINGLE PHASE, Conduction, Military, 60Hz, Multiple, Aircraft, Industrial,
Power Supply
Features:
- 115Vac Input
- Chassis Mount Power Supply
- N+1 Configuration
, CS7061A, +5Vdc 60A 300W, +12Vdc 3.0A 26W, -12Vdc 1.5A 18W, +24Vdc 3.0A 72W, 426W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
CTA803
This ruggedized military Commercial Off the Shelf (COTS) power supply operates from a 3-Phase 208Vac... More details >>CTA803
Telecom, Single, Military, 3-Phase AC-DC, AC THREE PHASE, 60Hz, Mil-Std, Forced Air,
Enclosed Case Power Supply
Features:
- AC‐DC Power Supply
- Three Phase 50/60Hz 208Vac Input (Line‐Line)
- +28 Output, 9000W Max
- Water Resistant (Sealed Enclosure)
- MIL‐STD‐810F Environmental *
- MIL‐STD‐461F EMI *
- MIL‐STD‐1275E +28V Vehicle Power *
- MIL‐STD‐1472F Safety Markings *
, CTA803, +28Vdc 322A 9000W, 9000W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
CTA804
This rugged PSU is designed for heavy-duty ground vehicle applications requiring 3-phase AC input and... More details >>CTA804
Single, 3-Phase AC-DC, AC THREE PHASE, 60Hz, Mil-Std, Forced Air,
Power Supply
Features:
- AC‐DC Power Supply
- Three Phase 50/60Hz 208Vac Input (Line‐Line)
- +270 Output, 11000W Max
- Water Resistant (Sealed Enclosure)
- MIL‐STD‐810F Environmental *
- MIL‐STD‐461F EMI *
- MIL‐STD‐1275E +28V Vehicle Power *
- MIL‐STD‐1472F Safety Markings *
- Enclosed case power supply
, CTA804, +270Vdc 40A 11000W, 11000W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
CWA003
This chassis mount slide-in filtered AC-DC power converter has multiple outputs available with N+1 redundancy.... More details >>CWA003
8U, Telecom, Single Phase AC, AC SINGLE PHASE, Military, 60Hz, Multiple, Mil-Std, Forced Air, Industrial, Ship,
Power Supply
Features:
- 115Vac +/- 10%, Single Phase, 60
Hz +/- 5% input power. Designed to meet portions of MIL-STD-704* - Designed to meet portions of Mil-Std-810F environmental specs.*
- Designed to meet portions of Mil-Std-461F for surface ship applications.*
- VME Power.
, CWA003, +3.3Vdc 84A 277W, +5Vdc 170A 847.5W, +12Vdc 33.3A 450W, -12Vdc 1.6A 19W, +15Vdc 5A 75W, +12Vdc 33.3A 400W, 1962W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
- 115Vac +/- 10%, Single Phase, 60
-
CWA005
This open frame filtered DC-DC power converter has multiple outputs available with N+1 redundancy. This... More details >>CWA005
2U, Telecom, Zero Hertz (DC), Military, Multiple, Mil-Std, Forced Air, DC-DC, DC HIGH VOLTAGE, Embedded Technology, VME, Industrial, Ship,
Power Supply
Features:
- 28VDC +/- .75V
- Designed to meet portions of
Mil-Std-810F environmental specs.* - Designed to meet portions of
Mil-Std-461 for surface ship
applications.* - VME Power.
, CWA005, +3.3Vdc 4A 13.2W, +5Vdc 43.5A 217.5W, +12Vdc 6.8A 82W, 311W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
CWA305
This liquid cooled DC-DC power converter has three outputs (+3.3Vdc, +5Vdc, and +28Vdc) and a... More details >>CWA305
Zero Hertz (DC), Military, Multiple, Mil-Std, Aircraft, DC-DC, DC HIGH VOLTAGE, Liquid,
Power Supply
Features:
- 270Vdc input. Multiple Output, 2368W Total.
- Designed to meet portions of Mil-Std-461E EMI specifications.*
- I2C temperature monitoring.
- Liquid Cooled enclosure 50/50 glycol and water mixture.
, CWA305, +3.3Vdc 210A 693W, +5Vdc 285A 1425W, +28Vdc 8.5A 239W, 2368W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
CWA401
This chassis pluggable slide-in filtered AC-DC power converter card has three DC outputs. The +5Vdc... More details >>CWA401
Telecom, Conduction, Military, Three Phase AC, AC THREE PHASE, 60Hz, Multiple, Mil-Std, Aircraft, 400Hz,
Enclosed Case Power Supply
Features:
- AC‐DC Power Supply
- Three Phase 60Hz/400Hz 115/208Vac Input
- 3 DC Outputs, 750W Max Combined Output
- 115Vac/208Vac 3‐phase input.
- MIL‐Std‐704A*
- Mil‐Std‐810F environmental specs. *
- Mil‐Std‐461E EMI specifications. *
, CWA401, +3.3Vdc 1.5A 5W, +5Vdc 64A 320W, +12Vdc 35.7A 428W, 375W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
EIA301
This chassis mounted air cooled AC-DC power supply has a six DC outputs. It operates... More details >>EIA301
Single Phase AC, AC SINGLE PHASE, Military, Multiple, Mil-Std, Forced Air, 400Hz, Industrial, Rack Mount,
Power Supply
Features:
- AC‐DC Power Supply
- Single Phase 400Hz 115Vac Input
- 6 DC Outputs, 225W Max Combined
Output - MIL‐STD‐704F* and MIL‐Std‐1399. *
- MIL‐STD‐810F Environmental *
- MIL‐STD‐461E EMI *
, EIA301, +3.3Vdc 12.75A 42.1W, +5Vdc 22A 110W, +/-12Vdc 1A 12W, +/-15Vdc 1.5A 22.5W, 221.1W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
ER8031A
The ER8031A is a dual input power supply where the input can be Primary Sourced... More details >>ER8031A
Single Phase AC, AC SINGLE PHASE, Military, 60Hz, Multiple, Mil-Std, Aircraft, Industrial,
Power Supply
Features:
- Chassis mount
- Dual Output
- Battery backup capability
- AC low indicator
- Battery loss indicator
- Mil-Std-461F EMI *
, ER8031A, +28Vdc 190W, 115Vac 145W, 335W @ 49ºC, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
ES6051A
The ES6051A is an AC-DC power supply that has been in production at Aegis Power... More details >>ES6051A
Telecom, 1-Phase AC-DC, AC SINGLE PHASE, Conduction, Military, 60Hz, Multiple, Mil-Std, Industrial, Rack Mount, Ship,
Power Supply
Features:
- Zeus Rack Mount
- Battery OK and Charged indicators
- Remote enable/disable
- Battery backup capability
- Designed to meet portions of MIL-
STD-461E CE102* for EMI
, ES6051A, +5Vdc 38A 190W, +12Vdc 0.83A 10W, -12Vdc 4.16A 50W, +36Vdc 2.6A 95W, 345W @ 60°C, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
GTA401
This chassis mounted filtered AC-DC power converter has Power Factor Correction and has been SWaP... More details >>GTA401
Telecom, 1-Phase AC-DC, AC SINGLE PHASE, Military, Multiple, Mil-Std, Forced Air, Aircraft, 400Hz, Industrial,
Power Converter
Features:
- 95/250Vac input.
- Designed to meet portions of MIL-Std-704F*
- Dual Output, 200W.
- Designed to meet portions of Mil-Std-810F environmental specs.*
- Designed to meet portions of Mil-Std-461F EMI specifications.*
, GTA401, 3.6Vdc 28A 100W, 5.3Vdc 19A 100W, 200W@ 65°C, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
GTA401-B
This filtered AC-DC power converter was designed for defense SDR technology, but may have many... More details >>GTA401-B
Telecom, 1-Phase AC-DC, AC SINGLE PHASE, Military, Multiple, Mil-Std, Forced Air, Aircraft, 400Hz, Industrial,
Power Converter
Features:
- 95/250Vac input.
- Designed to meet portions of MIL-Std-704F*
- Dual Output, 200W.
- Designed to meet portions of Mil-Std-810F environmental specs.*
- Designed to meet portions of
Mil-Std-461F EMI specifications.*
, GTA401-B, 3.8Vdc 26.8A 100W, 5.6Vdc 17.3A 100W, 200W@ 65°C, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
GTA701
This chassis mounted AC-DC power converter offers 0.97 Power Factor Correction, EMI filtering, and four... More details >>GTA701
1-Phase AC-DC, AC SINGLE PHASE, Military, Multiple, Mil-Std, Forced Air, Aircraft, 400Hz, Industrial,
Power Supply
Features:
- 95/250Vac input.
- Designed to meet portions of MIL-Std-704F*
- 4 Output, 325W.
- Designed to meet portions of Mil-Std-810F environmental specs.*
- Designed to meet portions of Mil-Std-461F EMI specifications.*
, GTA701, 3.6Vdc 11.11A 40W, 6Vdc 25A 150W, 12Vdc 10A 120W, 12Vdc 1.25A 15W, 325W, Aegis Power Systems, Inc, Aegis Power Systems, Inc
-
GTA805
This ruggedized military Commercial Off the Shelf (COTS) power supply operates from aircraft 400Hz power.... More details >>GTA805
Telecom, 1-Phase AC-DC, AC SINGLE PHASE, Military, Multiple, Mil-Std, Aircraft, 400Hz, Industrial,
Power Supply
Features:
- Single phase, 95-250 Vac
- 47Hz to 440Hz (Optimized for 400Hz)
- Designed to meet requirements of MIL-STD-810F
- Designed to meed EMI requirements of MIL-STD-461F
, GTA805, 3.6Vdc 21.7A 75W, 6Vdc 17.5A 105W, 12Vdc 0.834A 10W, 190, Aegis Power Systems, Inc, Aegis Power Systems, Inc
1–24 of 46 results
